KNX presence detector for flush-mounted wall installation, detection range 16 x 10 m, 2 x light, 2 x HVAC, installation height 2.20 m

Passive infrared presence detector for flush-mounted wall installation, 2 channels for lighting and 2 channels for HVAC, KNX Data-Secure, with Theben cover frame, cover frame for integration into common switch ranges available as an accessory, rectangular detection range 170° up to 16×10 m, mounting height 2.20 m, automatic presence and brightness-dependent control for lighting, switching or constant light control with standby functionality (orientation light), Dimmable lighting in switching mode with and without daylight influence, 2 binary inputs and 6 logic channels (AND, OR, XOR), aura function, scene functionality, integrated orientation light (white), integrated temperature sensor, Acoustic function, operation as fully or semi-automatic, switchable, adjustable brightness switching value, teach-in function, adjustable switch-on delay and follow-up time, detection range can be restricted, integrated button freely parameterizable (can be blocked), detection range can be extended via master/slave circuit, remote controllable

Download more information

More information

Data Sheet:
View
