Presence sensor for ceiling mounting, DALI-2 certified, rectangular detection area 360°, up to 30 m x 5 m (150 m²)

Presence sensor for ceiling mounting, DALI-2 certified, rectangular detection range 360°, up to 30 m x 5 m (150 m²), 2-way mixed light measurement, 3 instances for presence – Detection area zone 1 + 2 / zone 1 / zone 2, 3 instances for brightness – zone 1 + 2 / zone 1 / zone 2, provides information about “presence” and “brightness” as a DALI telegram in accordance with IEC 62386 parts 303/304, easy adjustment of brightness measurement, test mode for checking function and detection range, adjustable detection sensitivity, a multi-master application controller is required for commissioning/control and configuration, which must support parts 101/103 and optionally 301/303/304 in accordance with IEC 62386

Download more information

More information

Data Sheet:
View
