Flush-mounted 1-gang wireless DALI actuator, KNX RF, Data Secure, DALI-2 certified, interface between the DALI and KNX bus systems, easy commissioning of up to 30 ECGs in broadcast mode, control of RGB, RGBW, tunable white, or conventional luminaires, Support for DT-8 luminaires, Easy replacement of ECGs in case of failure, Universal mounting thanks to particularly compact housing, 2 binary inputs for potential-free contacts such as buttons, switches, window contacts, temperature sensor (input I2), Binary input I1 is assigned to the output ex works (function test and operation even without programming), integrated temperature monitoring for increased operational safety, e.g., in case of overload, secure communication through support of KNX Data Secure
Data Sheet:
View
