Passive infrared presence detector for flush-mounted wall installation, 2 channels for lighting and 2 channels for HVAC, KNX Data-Secure, with Theben cover frame, cover frame for integration into common switch ranges available as an accessory, rectangular detection range 170° up to 14×17 m, automatic presence and brightness-dependent control for lighting, switching or constant light control with standby functionality (orientation light), Dimmable lighting in switching mode with and without daylight influence, 2 binary inputs and 6 logic channels (AND, OR, XOR), aura function, scene functionality, integrated orientation light (white), integrated temperature sensor, Acoustic function, operation as full or semi-automatic, switchable, adjustable brightness switching value, teach-in function, adjustable switch-on delay and follow-up time, restriction of the detection range possible, integrated button freely parameterizable (can be blocked), extension of the detection range through master/slave circuit, remote controllable
Lejupielādēt vairāk informācijas
Datu lapa:
Skatīt
