KNX multisensors, kas sastāv no KNX pasīvās infrasarkanās klātbūtnes detektora un telpas gaisa sensora

KNX multisensor, consisting of KNX passive infrared presence detector and room air sensor (= 2 bus participants), room air sensor functions: Measures CO2 concentration, relative humidity, temperature, and air pressure, three independent parameterizable thresholds for CO2 concentration and relative humidity, integrated room temperature controller, 4 binary inputs, presence detector functions: KNX presence detector for ceiling mounting, square detection area 360°, up to 10 x 10 m (100 m²), three light channels for controlling three light groups, switching or constant light control, switchable between fully automatic and semi-automatic operation, brightness channel with cyclic output, channel for room monitoring, reduction of light follow-up time for short periods of presence, mixed light measurement, self-learning light switch-off delay, switching between 2 brightness setpoints, brightness setpoints adjustable via bus, Standby functionality, 2 presence channels with switch-on delay/inactive, switch-off delay adjustable, paraMeters remotely controllable and readable, master/slave operation selectable, test functions, scene control with two scenes, 8-bit scenes, integrated bus coupler
